Kev piav qhia
Universal flange adapters yog tsim rau kev sib txuas ntawm cov kav dej, uas ib qho kawg yog flanges thiab lwm qhov kawg yog qhov (socket). Cov flange adapters siv cov cuab yeej sib txuas tshiab tuaj yeem ntsia tau yooj yim thiab raug tshem tawm yooj yim.
Flange adapter yog cov khoom siv tau zoo thiab ntau yam khoom siv uas tau siv dav hauv kev tsim kho thiab kev tsim vaj tsev nyob thoob plaws ntiaj teb. Nws yog tsim los txuas cov kav dej nrog ntau hom flange, ua rau nws yog ib qho kev daws teeb meem zoo tshaj plaws rau cov xwm txheej uas tsis sib haum xeeb flange sib txuas yuav tsum tau koom nrog.
Ib qho ntawm cov txiaj ntsig tseem ceeb ntawm flange adapter yog nws lub peev xwm los tiv thaiv kev kub siab thiab huab cua kub. Qhov no ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov ntawv thov xws li cov chaw kho dej, cov roj refineries, thiab cov nroj tsuag tshuaj. Nws kuj tseem muaj lub neej ntev, uas txhais tau hais tias tus nqi tu qis thiab muaj zog ntxiv rau lub sijhawm ntev.
Lwm qhov zoo ntawm flange adapter yog nws qhov yooj yim ntawm kev teeb tsa. Nws tuaj yeem txuas tau sai thiab yooj yim rau ntau hom yeeb nkab siv cov cuab yeej txheem, tsis tas yuav tsum tau vuam lossis cov cuab yeej tshwj xeeb. Qhov no txhais tau tias nws tuaj yeem ntsia tau sai thiab ua tau zoo, tso cai rau kev tsim kho kom tiav sai dua thiab muaj teeb meem tsawg dua.
Flange adapters kuj yog customizable heev, nrog rau ntau qhov ntau thiab tsawg thiab configurations muaj kom haum rau cov kev xav tau sib txawv thiab kev siv. Lawv tuaj yeem tsim los ntawm ntau yam khoom siv, suav nrog hlau, hlau, thiab yas, nrog rau cov txheej txheem sib txawv thiab ua tiav los txhim kho lawv cov kev ua tau zoo thiab kav ntev.
Zuag qhia tag nrho, lub flange adapter yog ib qho kev txhim khu kev qha thiab cov nqi tsim nyog rau kev sib txuas cov kav dej nrog cov flange tsis sib xws. Nws versatility, durability, thiab yooj yim ntawm installation ua rau nws yog ib tug zoo xaiv rau ntau yam kev tsim kho thiab engineering tej yaam num.
Qhov zoo
1. Cov kab tso cai muaj 60 deviation thaum txuas cov kav dej rau lub cev txav ntawm cov yeeb nkab, vim qhov loj ntawm txoj kab uas hla ntawm cov yeeb nkab txuas nrog flange adaptor.
2. Universal flange adaptoris drilled rau kev sib raug zoo nrog PN10 thiab PN16.
3. Lub flange adapter yog tsim rau cov kav dej, xws li cov kav hlau kav, cov kav dej ua vaj tse, cov kav hlau, cov kav dej asbestos cement, PVC kav, GRP kav thiab ABD kav.
Cheebtsam
Tsis muaj. | Ib feem | Khoom siv |
1 | Lub cev | Hlau Hlau |
2 | caj pas | Hlau Hlau |
3 | Gasket | NBR/EPDM |
4 | Bolt | Hlau / Stainless hlau |
5 | Txiv ntseej | Hlau / Stainless hlau |
6 | Lub tshuab ntxhua khaub ncaws | Hlau / Stainless hlau |
Qhov ntev
DN (mm) | PN | OD Ntau | L | M-E |
50 | 10/16 | 59-72 | 75 | 4-M12 |
65 | 10/16 | 72-85 | 75 | 4-M12 |
80 | 10/16 | 88-103 | 75 | 4-M12 |
100 | 10/16 | 108-128 | 75 | 4-M12 |
125 | 10/16 | 132-158 | 75 | 4-M12 |
150 | 10/16 | 158-182 | 75 | 4-M12 |
175 | 10/16 | 189-212 | 75 | 4-M12 |
200A | 10/16 | 189-212 | 75 | 4-M12 |
200B | 10/16 | 218-235 | 75 | 4-M12 |
250A | 10/16 | 244-276 | 90 | 6-M12 |
250B | 10/16 | 271-289 | 90 | 6-M12 |
300A | 10/16 | 315-332 | 90 | 6-M12 |
300B | 10/16 | 322-350 | 90 | 6-M12 |
350 | 10/16 | 350-378 | 100 | 8-M12 |
400A | 10/16 | 386-428 | 100 | 8-M12 |
400 | 10/16 | 425-442 | 100 | 8-M12 |
500 | 10/16 | 527-544 | 100 | 10-M16 |
600 | 10/16 | 630-647 | 100 | 10-M16 |
